Lison 7245

Nominal Capacity: 40Ah

Nominal Voltage: 76.8V

Cell Material: LiFePO4

Configuration: 24S2P

Dimensions (mm): 360*220*173

Package Dimensions (mm): 413*273*230

Weight: 20kg
Specifications

Model

Lison 7245

Nominal Capacity

40Ah

Nominal Voltage

76.8V

Cell Material

LiFePO4

Configuration

24S2P

Dimensions (mm)

360*220*173

Package Dimensions (mm)

413*273*230

Weight

20kg

Continuous Discharge Current

60A

Peak Discharge Current

80A Until over temperature protection

Communication Method

Bluetooth

Protection Level

IP67

Matched Motors

≤1500W

Charging Parameters

76.8V/5A/10A/16A

Operating Temperature

Charge - 10 ~ 55°C；

Discharge - 20 ~ 60°C
